High Efficiency Multi-blade Stone Cutting Machine(

• Place of Origin:

   China

• Type:

  Sawing and Cutting Machinery

• Genre:

  Machinery & Equipment

• sCode:

  STPR1426703

• Place of Origin:

  China
• Applications:
  It is one of the large-scale stone processing machines designed and manufactured by our factory. It’s widely used to cut the thin slates of granite and marble. It’s of frame structure and high efficiency, with excellent ability, stable performance, agile operation, high automation and simple installation, operation, maintenance. Compared with single-blade cutting machine, it has the feature of lower energy consumption and less wastage of blades and segments. It’s the first-line choice for the granite and marble processing factories.
  Features of QZD-1600（QZD-160） High Efficiency Multi-blade Stone Cutting Machine(Hydraulic up/down)
  It adopts large-area contacting rails and double hydraulic cylinder up-and-down movement to improve the moving up speed. Overall protection of this machine has greatly enhanced stability of the machine to make sure the higher efficiency, longer life-span and lower maintenance rate.
  DataQZD-160
  No. of bladespc12(6-Φ1600,6-Φ940)
  16(8-Φ1600,8-Φ940)
  20(10-Φ1600,10-Φ940)
  Blade vertical strokemm1000
  Main motor powerkw55/65/75/90
  Water consumptionm3/h16
  Max. cutting sizemm3500×1300×650
  3500×1300×850
  Dimensions (L×W×H)mm8500×4000×5500
  Weight kg≈9000
